• A full range of profiles and sizes to suit all types of construction requirements
• Sure-Stop® PVC Waterstops conform to, and exceed all major international standards
• High quality compounded PVC for long term durability and integrity
• Factory made intersections to simplify and minimise on-site fabrication
• On-site welding equipment is available upon request
• Internal profiles come with factory pre-punched eyelets for easy and secure wire tying to
  reinforcement
• Ability to withstand high hydrostatic head pressures

Water retaining structures:

• Water tanks
• Water treatment plants
• Sewage treatment plants
• Swimming pools
• Dams and spillways
• Reservoirs
• Bund walls

Water excluding structures:

• Basements
• Underground car parks
• Tunnels
• Retaining walls
• Suspended slabs
• Below ground slabs
• Roof & podium slabs

Note : The product’s design and performance, its intended use, installation and final confirmation and approval for use, must be provided by the project’s Design Engineer and Project Manager.

Refer to the product brochure for diagrams of Expansion Joint and Construction Joint applications.

COLOUR –  Orange
PACKAGING – 150mm – 200mm = 20m roll, 250mm = 15m roll,
320mm = 12m roll
ROLL WEIGHT – Dependent upon profile type
STORAGE CONDITIONS & SHELF LIFE – 5 years from the date of production if stored properly in original, unopened and undamaged sealed packaging, in dry conditions out of direct sunlight at temperatures between +10°C and +40°C
MATERIAL TYPE – Polyvinyl Chloride (PVC)
WELDING TEMPERATURES – Approximately 190°C – 200°C
SERVICE TEMPERATURE RANGE –  -25°C to +70°C

Refer to CORKJOINT®’s in house Certificate of Analysis (COA) dated 31/12/2022 for test results pertaining to the above. A COA is conducted on every batch of raw material that is used in the production of Sure- top® PVC waterstops. Independent laboratory test results are also available upon request. Project specific material properties can be custom compounded to suit. Material properties can vary between batches.

NOTE: Full dimension drawings available upon request.

A wide range of standardised prefabricated intersection pieces are available allowing easy site welding of butt joints to Sure-Stop® PVC Waterstop junction pieces. Customised pieces can be made to suit. In such cases, drawings must be provided giving exact dimensions and jointing details.

The width of waterstop depends upon the thickness of the concrete and positioning of the reinforcement. The thickness of the concrete should be greater than or equal to the width of the waterstop profile. Refer to your engineer for further clarification and approval.

INTERNAL & EXTERNAL STYLE SURE-STOP® PVC WATERSTOPS

1. Prior to placement, all Sure-Stop® PVC Waterstop joins and intersections must be welded together on site using our recommended welding and joining procedure (refer to our “CORKJOINT® Sure-Stop® PVC Waterstop Site Joining Guidelines” brochure).
2. Sure-Stop® PVC Waterstop should be positioned inside the joint so that one half of the waterstop width is embedded into each concrete pour. (Refer FIG. 1).
3. INTERNAL Sure-Stop® PVC Waterstops must be securely tied into position through the pre-punched brass eyelets located on the external outer flanges of the waterstop. These are positioned every 300mm apart along both outer edges of the waterstop, giving a very secure fixing position. In vertical joint applications, the placement of form work is then positioned below and on top of the waterstop by butting up to it from both sides, achieving a split formwork outcome, which also helps secure/hold the waterstop into position. (Refer FIG. 2 ) Usually in horizontal joint applications no formwork is required.
4. EXTERNAL Sure-Stop® PVC Waterstop are secured into position by concrete nails that are hammered through the specially designed outer flange areas of the waterstop, into the lean concrete base (blinding layer) for slab on ground applications or by nails or screws into the formwork, for wall applications. In vertical joint applications the placement of formwork is then positioned on top of the waterstop by butting up to it. This also helps secure/hold the waterstop into position. (Refer FIG. 3)
5. To achieve the ultimate installation procedure, carefully place the concrete so as not to displace Sure-Stop® PVC Waterstop from its position. Thoroughly vibrate concrete around the waterstop to avoid air entrapment and to provide a positive contact between the waterstop and the concrete. Particular care should be taken when installing internal waterstops for slab on ground applications to make sure concrete is fully vibrated and compacted around and underneath the waterstop and all its ribs. (Refer FIG. 4).
6. Please also refer to our “CORKJOINT® Sure-Stop® PVC Waterstop Site Joining Guidelines” for further information on Sure-Stop® PVC Waterstop welding / joining procedures and preparation and installation procedures.

Where shown on the drawings waterstops shall be Sure-Stop® PVC Waterstop (state profile number required) as supplied by CORKJOINT®. Provide factory made waterstop fabrications for all changes of direction, intersections and transitions, leaving only straight butt joined splices for on-site fabrication.

 Joining of PVC Waterstops is performed by heat welding which results in the discharge of hydrogen chloride mist and vapour. In confined spaces or in still air conditions, the use of a ventilation fan or suitable respirator should be used, and the advice and approval of the Site Safety Supervisor is essential. For further information or advice on health and safety precautions, safe handling, storage and correct disposal of products, please refer to the most recent product Safety Data Sheet (SDS), which is available upon request.

CORKJOINT® undertakes modifications to its product brochures on a continual basis, as and when required.
Please check under the product summary section at www.corkjoint.com to ensure that you have the latest version of our product brochures.

The information and the recommendations relating to the application and end use of this product are given in good faith and are based on the information provided by the manufacturer of the product and/or the Company’s current knowledge and experience in connection with the product when properly stored, handled and applied under normal conditions and no liability of final function at the job site is assumed. In practice, the differences in materials, substrates and actual site conditions are such that no warranty in respect of merchantability of, or fitness for, particular purpose, nor any liability arising out of any legal relationship whatsoever, can be inferred either from this information, or from any written and/or oral recommendations, or from any other advice offered by the Company. The Company also has no express or implied knowledge of any particular purpose for which the product is required and any such information given will not be taken into account in the supply of this product. No responsibility or liability by the Company will be accepted for misuse, misreading or derivation from recommended guidelines in respect of this product and the user shall determine the suitability of the product for his intended use and assume all risks and liability in connection therewith. The information contained in our brochure may change at any time without notice. Any use of this product, Sure-Stop® PVC Waterstop, in any application should be approved as suitable for use/application by the Design Engineer and Project Manager.

• Conforms easily for installation onto rough or smooth concrete
  surfaces.
• Excellent adhesion to concrete with CJ-100 Adhesive.
• Allows concrete to gain strength before expansion due to
  built-in expansion control system.
• For use in horizontal and vertical construction joints.
• Long term durability & integrity.
• Can be bedded into the wet concrete of the first pour for
  installation.
• No compaction or displacement problems.
• Unaffected by repeated wet and dry cycles.
• Has the ability to bond to both concrete surfaces.
  No on-site welding required.
• Can withstand 60 metres (6.0 Bar) of hydrostatic head pressure.
• Ability to handle long-term exposure to the environment prior
  to the 2nd pour taking place.
• Non-toxic and requires no special handling.
• NSF Certified for use in potable water applications.
  Very easy to handle and install

Refer to the specific Product Brochure for the related Physical & Performance Properties.

Note : The above Physical Property results are obtained from our internal Certificate of Analysis (COA) testing from a specific batch. Material properties can vary between batches.

Refer to the specific Product Brochure for the related Packaging & Dimensions.

Water retaining structures:

• Water tanks
• Water treatment plants
• Sewage treatment plants
• Swimming pools
• Dams and spillways
• Reservoirs
• Bund walls

Water excluding structures:

• Basements
• Underground car parks
• Tunnels
• Retaining walls
• Suspended slabs
• Below ground slabs
• Roof & podium slabs

Other:

• New to Old Concrete
• Poured in-situ construction joints
• Roof Slabs
• Suspended slabs
• Suspended slabs
• Above & below grade precast panels
  (check with CORKJOINT® & your Engineer)

Note : The product’s design and performance, its intended use, installation and final confirmation and approval for use, must be provided by the project’s Design Engineer and Project Manager.


Note : Refer to above minimum concrete cover requirements. Please refer to CORKJOINT® for further information.

Due to expansive forces, Superswell® 47B should be both detailed and installed with a minimum 50mm clear cover to the face of the concrete. Expansion rate can vary in salt and contaminated water. Increase cover when using light weight, low strength concrete. Not for use where excessive shrinkage of the concrete may occur at the joint faces. Do not stretch the Superswell® 47B during installation. Not for use in movement (expansion, isolation and contraction) joints.

HYDROSTATIC HEAD PRESSURE RESISTANCE – 60 METRE (6 BAR)

Refer to the specific Product Brochure for the related information.

EXPANSION RATE PROPERTIES – 30 DAY IMMERSION DURATION

Refer to the specific Product Brochure for the related information.

Superswell® 47B requires a minimum 50mm cover of concrete from the outside edge.

1. Brush off any dust or debris from the surface where the Superswell® 47B is to be applied. Brush a coat of CJ-100 Adhesive 30mm wide onto the concrete surface and one coat to the surface of the Superswell® 47B.
2. Once both surfaces where the adhesive was applied are touch dry, with the use of your thumbs or heel of your hand, firmly press a continuous bead of Superswell® 47B into position, making sure you achieve full contact with the adhesive on the concrete surface. Do not stretch the Superswell® 47B when applying it into position.
3. Use a neat, firm butt join to join Superswell® 47B together and then knead the ends together to form a continuous uninterrupted gasket. This type of join is used for continuous placement of  Superswell® 47B and for any intersection joins.
4. Check to see that the Superswell® 47B has totally adhered to the concrete surface. If the surface is rough or irregular, you may need to use a firmer hand pressure to make sure that the Superswell® 47B has full contact with the surface. There must be no visible gaps under the Superswell® 47B after installation.
5. The protective paper layer cover on the Superswell® 47B can be removed any time prior to the second pour of concrete taking place.
6. Placement of the second pour of concrete can be applied once the CJ-100 Adhesive has dried. Upon pouring, make sure the concrete is properly compacted and vibrated around the Superswell® 47B.
7. If the Superswell® 47B has been exposed to water (moisture) prior to the second pour taking place, check for pre-expansion. If the product has pre-expanded, then remove that section and replace with a new length of Superswell® 47B.
8. For vertical construction joints and overhead applications, it may be necessary to also secure the Superswell® 47B with nails, placed approximately every 250mm apart. This is usually only required as extra security if you need to pour your concrete prior to the CJ-100 Adhesive drying completely.

Refer to the Product Brochure for more details.

• Exposure & Water Immersion Expansion in Potable Water
  Exposure & Hydrostatic Head
• Pressure (cyclic wet & dry) in Potable Water – 60m (6.0 Bar)
• Water Immersion Expansion in Salt Water (5% NaCI)
• Hydrostatic Head Pressure in Salt Water (5% NaCI) – 60m (6.0 Bar)
  National Sanitation Foundation
• (NSF) Certification for Potable Water Use

Note : The above test reports are available upon request.

Waterstops where shown on the drawings shall be Superswell® 47B controlled expansion waterstop as supplied by CORKJOINT®. The waterstop is to have a built-in expansion control system to minimise any pre-expansion prior to the second pour taking place and be able to withstand up to 60 metres (6.0 Bar) hydrostatic head pressure resistance. The waterstop is to be placed in accordance with the manufacturer’s installation guidelines, and the Design Engineer’s specification.

In confined spaces or in still air conditions, the use of a ventilation fan or suitable respirator should be used, and the advice and approval of the Site Safety Supervisor is essential. For further information or advice on health and safety precautions, safe handling, storage and correct disposal of products, please refer to the most recent product Safety Data Sheet (SDS), which is available upon request.

The information and the recommendations relating to the application and end use of this product are given in good faith and are based on the information provided by the manufacturer of the product and/or the Company’s current knowledge and experience in connection with the product when properly stored, handled and applied under normal conditions and no liability of final function at the job site is assumed. In practice, the differences in materials, substrates and actual site conditions are such that no warranty in respect of merchantability of, or fitness for, particular purpose, nor any liability arising out of any legal relationship whatsoever, can be inferred either from this information, or from any written and/or oral recommendations, or from any other advice offered by the Company. The Company also has no express or implied knowledge of any particular purpose for which the product is required and any such information given will not be taken into account in the supply of this product. No responsibility or liability by the Company will be accepted for misuse, misreading or derivation from recommended guidelines in respect of this product and the user shall determine the suitability of the product for his intended use and assume all risks and liability in connection therewith. The information contained in our brochure may change at any time without notice. Any use of this product, Superswell® 47B, in any application should be approved as suitable for use/application by the Design Engineer and Project Manager.

• Simple and fast to install. Easy to cut, weld and join.
• A joint waterproofing membrane and joint sealing system in one.
• Physically strong with high elongation capabilities.
• Able to accommodate movement in longitudinal, lateral and vertical directions.
• Ability to be installed on many different types of substrates and for use in many different type of projects.
• Joining of product is by heat welding providing an integrated continuous membrane.
• Factory made intersection pieces available for intersecting joint locations allowing for fast and easy installation.
• Good chemical resistance to hydrocarbons, oils, fuels and acids.
• Resistant to constant exposure to water.
• Available in widths of 200mm and 300mm for use in small or wide joints.
  Can be used in conjunction with other waterstop systems as added benefit/protection to the structure and to the system.
• Installs at a wide range of temperatures and climatic conditions with resistance to UV.

Note : The products design and performance, its intended use, installation and final confirmation and approval for use, must be provided by the project’s Design Engineer and Project Manager.

• For use in non-moving or moving joints in concrete.
  For use as a flexible waterproofing membrane for expansion joints subject to large movement.
• A joint waterproofing membrane for use in tunnels, bridges and road works.
• Sealing of joints in water works for water tanks, reservoirs, dams, water treatment plants, sewage
  treatment plants and swimming pools, if used in-conjunction with an appropriate joint waterstop.
• Sealing of construction joints and expansion joints in buildings, podium decks and flat roofs.
• For use in wet areas where a flexible joint membrane can easily conform to joint corners in bathrooms and toilets.
• Trafficable joints in floor slabs if a suitable joint cover system is used as protection over the top.
  Sealing of joints in precast structures.
  Sealing of structural joints in facades.
  Over cracks in concrete

Note : The product’s design and performance, its intended use, installation and final confirmation and approval for use, must be provided by the project’s Design Engineer and Project Manager.

Refer also to the Product Brochure.  Click on image for full screen view.

• J-Seal® EX 200 for joint widths up to 50mm
• J-Seal® EX 300 for joint widths up to 100mm

Note : If high joint movement is expected then refer to the required installation procedures stated under “Membrane Installation”. Membrane should not be elongated more than 25% under tension from its original size.

Note : Refer to CORKJOINT®’s in house Certificate of Analysis (COA) for test results pertaining to the above. Internal COA’s are conducted on every batch of raw material that is used in the production of J-Seal® EX. Independent laboratory test results are also available upon request. Project specific material properties can be custom compounded to suit. Material properties can vary between batches.

 SURFACE PREPARATION

The surface to receive the membrane must be prepared thoroughly before applying the
adhesive and membrane, free from oil, grease, paint, dust, laitance and water. Make sure that the surface and joint edges are structurally sound, smooth, flat and free of any deep holes or protrusions. Rough surfaces or voids should be flattened mechanically with a grinder and deep voids or holes filled with a high-quality non-shrink grout or mortar.

If the surface has existing oil, grease, paint, solvent, form-oil, mould or algae present, sand blast or grind back to good clean, sound concrete.

For installation for an expansion joint, chamfer the joint edges with a 5mm to 10mm angle so to remove the sharp edge.

For new concrete application, the concrete must be a minimum of 28 days old.

ADHESIVE FOR BONDING

CORKJOINT® CJ Epoxy Adhesive two-component, low viscosity, thixotropic epoxy adhesive (refer to individual product brochure for further information).

PREPARATION OF ADHESIVE FOR BONDING

Refer to CORKJOINT® CJ Epoxy Adhesive Product Brochure for mixing directions.

MEMBRANE INSTALLATION

Apply a 2.0mm thick application of CJ Epoxy Adhesive onto the concrete surface on each side with a metal scraper or trowel. Once the CJ Epoxy Adhesive is applied, remove the internal masking tape application on each side, prior to applying the membrane.

Lift and lay the membrane into position and lightly push the outer fixing section of the membrane into the adhesive on each side so the adhesive pushes through the fixing holes. Apply another 2.0mm thick layer of CJ Epoxy Adhesive on top of the membrane fixing section and smooth it out accordingly with a suitable trowel assuring full compaction of the adhesive and membrane, and removing any air pockets. Immediately remove the masking tape from each outside edge. Refer to Figure 3 under Installation Drawings.

If the membrane is to have any floor covering, concrete topping, ceramic tiles or mechanical cover applied over it, then sprinkle a light application of fine quartz sand on to the top coat application of adhesive to create a rough surface for bonding. This is to be done prior to the second layer of masking tape removal and while the adhesive is still wet. Once the adhesive is dried, brush away any loose sand.

Protection from damage must be applied over the membrane during the application and finishing processes of the membrane and concrete surface coverings.

For installation of membrane over cracks apply the same installation procedures as above. Refer to Figure 5 under Installation Drawings.

MEMBRANE JOINING

If a length of membrane is required to be joined, then overlap one section of membrane to the other by 50mm and then heat weld the join overlap section by hot air welding. Be careful not to burn or char the membrane. Once the required melt is achieved, firmly press the membrane down on to the other with a hand roller or other type of suitable tool, applying firm hand pressure to remove any air pockets or creases. Allow the join to cool for 5 minutes and do not bend or pull the membrane. The above procedure is also used for joining of Intersection pieces. Factory made Intersection pieces are available by order. Refer to CORKJOINT®’s Job Site Welding/ Joining Procedures for further information.

•  Sharp object penetration, perforation loading or mechanical damage.
• Non-trafficable with direct traffic loading on to the membrane. If J-Seal® EX TPER is to be used for a trafficable joint, then a suitable joint cover system should be applied over for protection.
• High hydrostatic head pressures unless used in conjunction with an appropriate joint waterstop system. Refer to CORKJOINT® for further information on suggested waterstop system to consider.
• If J-Seal® EX TPER is to be applied in areas of direct water pressure (positive side) for a slab or wall joint, then the under-side of the membrane must be supported by an appropriate expansion joint fillerboard. For a wall joint application on the negative side, please contact CORKJOINT® for further information.
• Exposure to direct sunlight or UV for extended periods.
• Check compatability for use with other joint systems, joint sealants or waterproofing membranes.

A wide range of standardised prefabricated intersection pieces are available allowing easy site welding of butt joints to J-Seal® EX TPER junction pieces. Customised pieces can be made to suit. In such cases, drawings must be provided giving exact dimensions and jointing details.

Where shown in the Product Brochure drawings, the joint sealing and waterproofing membrane shall be J-Seal® EX TPER Sealing and Waterproofing Membrane (State profile number required) as supplied by CORKJOINT®. The application/installation of the product must be in accordance with the manufacturer’s recommendations. (State profile number required) as supplied by CORKJOINT®. The application / installation of the product must be in accordance with the manufacturer’s recommendations.

Joining of J-Seal® EX TPER is performed by heat welding which results in the discharge of hydrogen chloride mist and vapour. In confined spaces or in still air conditions, the use of a ventilation fan or suitable respirator should be used, and the advice and approval of the Site Safety Supervisor is essential. For further information or advice on health and safety precautions, safe handling, storage and correct disposal of products, please refer to the most recent product Safety Data Sheet (SDS), which is available upon request.

The information and the recommendations relating to the application and end use of this product are given in good faith and are based on the information provided by the manufacturer of the product and/or the Company’s current knowledge and experience in connection with the product when properly stored, handled and applied under normal conditions and no liability of final function at the job site is assumed. In practice, the differences in materials, substrates and actual site conditions are such that no warranty in respect of merchantability of, or fitness for, particular purpose, nor any liability arising out of any legal relationship whatsoever, can be inferred either from this information, or from any written and/or oral recommendations, or from any other advice offered by the Company. The Company also has no express or implied knowledge of any particular purpose for which the product is required and any such information given will not be taken into account in the supply of this product. No responsibility or liability by the Company will be accepted for misuse, misreading or derivation from recommended guidelines in respect of this product and the user shall determine the suitability of the product for his intended use and assume all risks and liability in connection therewith. The information contained in our brochure may change at any time without notice. Any use of this product, J-SEAL® EX TPER Sealing and Waterproofing Membrane, in any application should be approved as suitable for use/application by the Design Engineer and Project Manager.
